Automotive 3-Phase Isolator MOSFET Drivers for Safety-Critical Applications

A6861, A6862

LP TSSOP 16 pin

The A6861/2 provides a safe and reliable solution for motor isolation in automotive systems, replacing electromechanical relays with solid-state control for enhanced performance and ASIL compliance. The A6862 offers additional flexibility with independent activation inputs

* Note: If you have issues logging into this feature you may need to enable 3rd party cookies in your browser settings

Top Features

Packaging

  • 3 floating N-channel MOSFET drives
  • Maintains VGS with 100 kΩ gate-source resistors
  • Integrated charge pump controller
  • 4.5 to 50 V supply voltage operating range
  • Independent TTL input for each phase
  • 150°C ambient (165°C junction) continuous


16-Pin TSSOP with exposed thermal pad (suffix LP)
