Evaluation boards offer a method for quickly evaluating Allegro current sensors in a lab environment without needing a custom circuit board. This document describes the use of the ACS772CB Evaluation Board. This evaluation board (TED-0003440) is intended for use with the ACS772CB custom 3-pin SOIC current sensor IC.
Product Details
Product Details
Top Features
- 8-layer PCB with 4 oz. copper weight on all layers
- Flexible instrument connection: Standard Keystone test points, banana jack connectors are provided
NOTE: If using the evaluation board with high currents, remove the banana jacks and use screws and lugs for connection.
Supported Products:
Content
- Printed circuit board with populated components.
- Recommended bill of materials (BOM) for all compatible current sensor are listed in the “Bill of Materials” section below.
