Allegro Launches Custom SOIC16W Package Ideal for Power Dense Hybrid and Electric Vehicles and Solar Applications

2月 13, 2020
ACS724-5 MC Package against Solar Panels

Brand new family of devices to offer 5kV certified isolation voltage and 80+A nominal current measurement—all in a tiny footprint.

Allegro MicroSystems, a global leader in power and sensing solutions for motion control and energy efficient systems, has announced the release of the brand-new custom SOIC16W package, named “MC”, which marks a leap forward in the industry’s current sensing capabilities for power dense applications that require high isolation with low power loss. This new package has an ultra-low 265uOhm series resistance—more than 2.5 times lower than existing SOIC16W solutions—while delivering Allegro’s highest certified isolation rating of 5kV.



The first devices available in this new package are Allegro’s current sensor ICs ACS724 and ACS725, both offering leading performance in terms of speed and accuracy. These devices are optimal for applications like DC/DC converters, solar inverters, UPS systems, xEV On Board Chargers (OBC), EV charging pile, and motor control.



Package provides higher power density with a smaller footprint

With a trend toward smaller solution size, engineers face more thermal challenges. The new MC package has a copper leadframe more than two times (2X) thicker than that of standard SOIC semiconductor packages. This allows for the ultra-low 265uOhm series resistance that improves current density in the Allegro package—and therefore power density in customers applications. At the same time, the SOIC16W footprint also allows for smaller PCBs. The package is capable of handling >80A of continuous current depending on operating temperature requirements and subsequently reduces the need for external cooling components.



“We all need to work toward a more sustainable future and Allegro’s innovations are leading the way. Designers of electric and hybrid vehicles are working to reduce the weight and size of their systems,” explains Shaun Milano, Business Unit Director for Current Sensors at Allegro. “They need to deliver higher power density solutions, and the new MC package now makes this easier than ever.”



Optimized Allegro patented construction improves isolation rating

Patented internal package constructions deliver another first for Allegro with a 5kV isolation rating that allows customers to operate at continuous voltages as high as 1600VDC and 1140VRMS. This meets the needs of the most demanding electric vehicle applications and the new 1500VDC solar standards.

For datasheets and more details on Allegro’s innovative current sensor family, including the ACS724/5 in the MC package, please visit allegromicro.com. Contact your local sales office for more information and to request samples today.
