Allegro 电流传感器

带 2.1 kVRMS 电压绝缘及低电阻电流导体的汽车级全集成、基于霍尔效应的线性电流传感器 IC

ACS715

Evaluation Board
ACS715 数据手册

Product Details

Top Features

  • 低噪音模拟信号路径
  • 可通过滤波引脚设置器件带宽
  • 5 µs 输出上升时间，对应步进输入电流
  • 80 千赫带宽
  • 一般总输出误差为 1.5%（当 TA = 25°C）
  • 小型低厚度 SOIC8 封装
  • 1.2 mΩ 内部传导电阻
  • 引脚 1-4 至 5-8 之间 2.1 VRMS 最小绝缘电压
  • 5.0 伏特，单电源操作
  • 133 至 185 mV/A 输出灵敏度
  • 输出电压与感测到的直流电流成比例
  • 出厂时精确度校准
  • 极稳定的输出偏置电压
  • 近零的磁滞
  • 电源电压的成比例输出
  • 工作温度范围为 -40°C 至 150°C

Part Number Specifications and Availability

设计工具

ECAD FILE

ACS715

ACS715 ECAD Model Type Image
Gerber File

ASEK7xx Gerber File
Simulation Tool

Current Sensor Error and Resolution
Software

Software Portal

Technical Documentation

Package Thermal Resistance for Allegro Current Sensors with Integrated Conductors
Application Note

Package Thermal Resistance for Allegro Current Sensors with Integrated Conductors

Glossary of Isolation-Related Terms for Integrated Current Sensors
Application Note

Glossary of Isolation-Related Terms for Integrated Current Sensors

Managing External Magnetic Field Interference When Using ACS71x Current Sensor ICs
Application Note

Managing External Magnetic Field Interference When Using ACS71x Current Sensor ICs

Certificate CB US 42876 UL LC Package
Certificate

Certificate CB US 42876 UL LC Package

Certificate of Compliance 20130417 E316429
Certificate

Certificate of Compliance 20130417 E316429

(Showing 4 (of 5
