40V, 3A Synchronous Buck Regulator Module with Integrated Inductor and EMI Filter

APM81911

APM81911 Product Image

The APM81911 provides a complete and efficient power solution for demanding applications, integrating a synchronous buck regulator, inductor, EMI filter, and low-Iq mode for reduced power consumption.

* Note: If you have issues logging into this feature you may need to enable 3rd party cookies in your browser settings APM81911 ECAD Model Type Image

Top Features

Typical Applications

Packaging

  • Wide VIN range, 3.5V to 36V operation with transients up to 40V
  • Ultra-Low EMI with integrated input and bootstrap capacitors, and inductor
  • Low Power Mode: 6µA Quiescent Current for increase battery life
  • Spread spectrum dithering switching
  • AEC-Q100 qualified for Automotive applications

The APM81911 includes a high-performance DC-DC regulator IC, a low DCR inductor and two capacitors in a compact 4mm x 6mm x 2.1mm NB-32 QFN package with Wettable Flanks.



Part Number Specifications and Availability

Documentation and Resources
