The ACS37041/2 current sensors simplify current measurement by eliminating the need for external shunt resistors, offering a compact, integrated solution with low ohmic loss and differential sensing for robust performance. The ACS37041 provides functional isolation up to 100 VRMS, while the ACS37042 offers basic isolation up to 285 VRMS.
Product Details
Product Details
Top Features
- Self contained shuntless current sensing with no
external sense resistor required; single package solution - Low ohmic loss with 1.6mΩ conductor resistance on the
LH package - Small footprint, SOT23-W 5 pin LH package
- 125 kHz bandwidth
- 100 VRMS working voltage for functional isolation (ACS37041)
- 285 VRMS working voltage for basic isolation (ACS37042)
Part Number Specifications and Availability
ACS37041 Product Overview
Allegro MicroSystems' latest innovation in current sensing technology, the ACS37041, is a high-performance, fully integrated current sensor IC that offers exceptional accuracy and reliability for a wide range of applications. For more detail into what the ACS37041 can do, check out our product overview.
0:00
Discover Allegro's Advanced Magnetic Current Sensors!
Upgrade your designs with efficient, compact, and integrated solutions. Simplify your circuits and reduce component count with Allegro's innovative sensor technology.
Replace the Shunt
