80V, 1.5A Synchronous Buck Regulator for 48V Automotive Systems

APM81815

40V Synchronous Buck Regulator Packaging Image

The APM81815 simplifies power supply design for 48V automotive systems, offering a high level of integration, low EMI, and selectable output voltages (3.3V, 5V, 5.35V, or 12V).

* Note: If you have issues logging into this feature you may need to enable 3rd party cookies in your browser settings APM81815 ECAD Model Type Image
View Datasheet
Navigate

Top Features

Typical Applications

Packaging

  • VIN operating range: 5 to 72 V
  • 1.5A continuous output current
  • Integrated Vin and Boot Cap to reduce component count and achieve ultra-low EMI
  • Thermally enhanced and space saving 4 mm × 4 mm × 2.1 mm wettable flank QFN package
  • 28 μA no-load quiescent current (48 VIN to 12 VOUT)
  • 2.15 MHz internally fixed and adjustable from 400 kHz to 2.4 MHz

The APM81803 features a 24-pin, 4 mm × 4 mm x 2.1mm QFN package with exposed thermal pads and wettable flank, (suffix NB).

× not found

Part Number Specifications and Availability

Documentation and Resources

Documentation

设计工具

Filter Document Type:
All Types
All Types Application Note Guide
Documents Found: 32
Document Type Document Name
Application Note
Allegro APM81815 Buck Power Module for 48V Bus: Insights on Power Loss and Thermal Performance
Guide
APM81815 Evaluation Board User Guide
Guide
APM81815 Design Tool
Filter Document Type:
All Types
All Types Simulation Tool
Documents Found: 32
Document Type Document Name
Simulation Tool
APM81815 Design Tool
