EV Chargers

EV chargers for electric cars must be safe and reliable. Compact current sensors from Allegro help minimize heat dissipation, and can be used in EV charging stations for both residential and commercial buildings. Level 1 and 2 EV chargers are the most common and affordable for households and businesses with EV charging stations installed in parking garages. Special commercial chargers, also called superchargers, are Level 3 Fast DC chargers that deliver >50kW power to high-end electric cars and EVs.

Drawing up to 80A of current, Level 1 and 2 EV chargers plug into 120 VAC/230 VAC wall outlets and can take advantage of our safe, reliable, and power-efficient solutions. Level 3 Fast DC chargers have hundreds of amps of current flowing through them, and high-voltage isolation is required to ensure user safety. Allegro core-based and coreless current sensors are perfect for cases where the lowest heat generation and the highest current sensing accuracy are needed.

Select a subsystem below to view related products.

Fast DC EV Charger Diagram
  • More

    DC/DC Controller Current Feedback Secondary Power Stage

    ACS772 – 0-400A Phase Current Sensor

    ACS37612 – >200A Coreless Differential Current Sensor IC

    A1367 – Low-Noise, High-Precision, Programmable Linear Hall Sensor IC

    Close
  • More

    DC/DC Controller Current Feedback Primary Power Stage

    ACS772 – 0-400A Phase Current Sensor

    ACS37612 – >200A Coreless Differential Current Sensor IC

    A1367 – Low-Noise, High-Precision, Programmable Linear Hall Sensor IC

    Close
  • More

    AC/DC (PFC Boost Circuit) Current Feedback

    ACS732 – 1 MHz Sensor and Over-Current Fault

    ACS37800 – AC & DC Highly Isolated Power Monitoring IC

    ACS772 – 0-400A Phase Current Sensor

    ACS37612 – >200A Coreless Differential Current Sensor IC

    A1367 – Low-Noise, High-Precision, Programmable Linear Hall Sensor IC



    Close
  • More

    Overcurrent Protection

    ACS37002 – High Accuracy Current & Fault Sensor

    ACS773 – 0-400A Phase Current Sensor

    A1367 – Low-Noise, High-Precision, Programmable Linear Hall Sensor IC

    Close
  • More

    DC Output Current Protection

    ACS37612 – >200A Coreless Differential Current Sensor IC

    ACS772 – 0-400A Phase Current Sensor

    ACS72981 – 0 to 200A  High Accuracy Hall Current Sensor

    Close
Level 1-2 EV Charger Diagram
  • More

    Input Current/Power Monitoring

    ACS37002 – High Accuracy Current & Fault Sensor

    ACS732 – 1 MHz Sensor and Over-Current Fault

    ACS733 – 1MHz Hall Current & Fault Sensor, SOIC16

    ACS772 – 0-400A Phase Current Sensor

    A1367 – Low-Noise, High-Precision, Programmable Linear Hall Sensor IC

    ACS37800 – AC & DC Highly Isolated Power Monitoring IC

    Close
  • More

    AC Output Current Protection

    ACS37002 – High Accuracy Current & Fault Sensor

    ACS772 – 0-400A Phase Current Sensor

    A1367 – Low-Noise, High-Precision, Programmable Linear Hall Sensor IC

    Close
  • More

    Overcurrent Protection

    ACS37002 – High Accuracy Current & Fault Sensor

    ACS773 – 0-400A Phase Current Sensor

    A1367 – Low-Noise, High-Precision, Programmable Linear Hall Sensor IC

    Close
  • More

    Actuator Motor Control

    A4950 – Full-Bridge PWM Motor Driver

    A5950 – Full-Bridge PWM Motor Driver w/Current Sense

    Angle Position Sensor

    A1333 – CVH Angle Sensor

    AAS33001 – CVH Angle Sensor

    Close
