Magnetic Position Sensors
Stray Field Immune, High-Speed, Hall-Effect Angle Sensor IC for Electrified Vehicles in Single and Dual Die Package
A33023
The A33023 is a 360° angle sensor IC for high-resolution angular position with low 25µs latency. It offers multiple output options (SPI, PWM, UVW, ABI), integrated linearization, and targets ASIL D compliance, making it ideal for fast, safety-critical automotive applications, qualified to AEC-Q100.
Product Details
Product Details
Top Features
- Stray-field immune
- Designed to meet ASIL D requirements when used in conjunction with appropriate system-level control
- High accuracy and resolution
- Low latency
- Wide operating voltage (3.7 V to 18 V)
Target Application
Part Number Specifications and Availability
