3D PCB-less Magnetic Position Sensor IC for Harsh Environments

A31316

The A31316 provides robust and reliable position sensing in harsh environments, with a PCB-less SIP package, integrated capacitor, and configurable signal path processing for simplified design.

* Note: If you have issues logging into this feature you may need to enable 3rd party cookies in your browser settings A31316 ECAD Model Type Image
Download Datasheet
Navigate

Top Features

Packaging

  • PCB-Less “UC” Package for system integration without a PCB
  • Linearization and binning modes (up to 33-point fixed, up to 22-point programmable positions)
  • Supports SENT (SAE J2716) and PWM interface options
  • Developed in accordance with ISO 26262 as a hardware safety element out of context (SEooC) with ASIL B
  • AEC-Q100 Grade 0 qualified supports operation in harsh conditions, required for automotive and industrial applications

The A31316 is available in a 3-pin PCB-less SIP package (suffix UC) with an integrated supply capacitor. The sensor has high robustness to mechanical vibration and contamination and can be over-molded or potted with plastic or epoxy for a tight seal.

UC Packaging Documentation
