APEK89301GES-01-T Evaluation Board

A89301 50V, Ultra-Low Noise FOC Motor Controller with I2C Control

The A89301 evaluation board is designed to aid system designers in evaluating the operation and performance of the A89301 motor controller IC. This user guide provides stepby- step instructions on how to use the A89301 evaluation board to program the Allegro A89301 motor controller IC. In addition, this document contains feature descriptions that are not shown in the A89301 datasheet

Features

Contents

  • USB communications to allow a GUI to control the device via I2C
  • Programs devices to control a motor

  • APEK89301GES-01-T evaluation board
