Two-Wire Hall-Effect Switch with Advanced Diagnostics for Functional Safety

APS11800

Allegro LH-UA Packaging

The APS11800 is designed for functional safety applications, offering integrated diagnostics, a safe state output, and compatibility with legacy two-wire systems, simplifying design and enhancing reliability.

* Note: If you have issues logging into this feature you may need to enable 3rd party cookies in your browser settings APS11800 ECAD Model Type Image

Top Features

Packaging

  • ASIL-B
  • AEC-Q100
  • Several magnetic switchpoint operations
  • Wide supply voltage range 3-24 V
  • TJ up to 175C
  • ±8 kV ESD Rating (HBM)
  • 40 V Load Dump compliance

3-Pin SOT23W (LH) and 3-Pin SIP (UA).

LH Package Documentation

UA Package Documentation
